DLE-CNC 1050

This kind of DLE-CNC1050 is the heavy-duty CNC Turning Lathe Machine with Maximum Loading Capacity of Work-piece Weight 10 Tons which is been made in ISO9001 factory from MAXNOVO MACHINE with CE Safety Certification. Such high performance of flat bed solid CNC Lathe Machine distinguishes itself by quality, accurate, sustainability and consistent value.

Availability:

Quantity:



Inquire Add to Basket

Type:
Flat Bed Heavy Duty CNC Lathe
Controller:
SIEMENS / FANUC / GSK
Max.Swing Over Bed:
2080 mm
Distance Between Center :
16000 mm
Main Motor:
30KW
Spindle Bore :
130 mm

Main Feature

DLE-CNC 1050 Extra Heavy Duty Universal Flat-Bed CNC Turning Lathe Machine with Rigid Wider Bed Width 1100 mm is Optimal Solution for Precision Machining of Big workpiece over 2080 mm diameter and up to 10 Tons

Convincing Arguments : Quality, Efficiency and Price

Max. Load Work-piece Weight Between Centers is 10 Tons
Max. Swing Over Bed is up Ø 2080 mm
Solid machine Bed Width is 1100 mm
CNC-controlled Flat-Bed Lathe Machine
Large spindle bore diameter up to Ø 130 mm
Longitudinal feed and Cross feeds by servo motor drive through ball screws
Polished ball screw spindles
Maintenance-friendly protective housing
Central Lubrication System
High-quality preloaded ball screws
Braced machine bed made from grey cast-iron
High precision frequency hardened guide-ways ensure more precision and longer working life
Complex spindle bearing
Safety Sliding doors
Hardened and ground slide ways
CNC Controlled lathe machine perfect for industry
Precise machining and central lubrication
Easy operation and low maintenance cost
Servo motor for X-axis and Z-axis as standard included
4-position Vertical Electrical Tool-Post included
Powerful 30 KW main motor as standard included
SIEMENS or FANUC or GSK CNC Control System is optional
Certificate of Original (CO, FORM A, FORM E, FORM F)

Technical Data

Product Name :	Heavy Duty CNC Lathe Machine
Product Item :	DLE–CNC 750	DLE–CNC 850	DLE–CNC 1000	DLE–CNC 1050
Bed Type :	Flat Bed	Flat Bed	Flat Bed	Flat Bed
Maximum Load Work-piece :	10 Tons	10 Tons	10 Tons	10 Tons
Bed Width :	1100 mm	1100 mm	1100 mm	1100 mm
Machine Data
Maximum Swing Over Bed :	Ø 1480 mm	Ø 1680 mm	Ø 1980 mm	Ø 2080 mm
Max. Swing Over Cross Slide :	Ø 1040 mm	Ø 1240 mm	Ø 1540 mm	Ø 1640 mm
Distance Between Centers :	2000 /3000 /4000 /5000 /6000 /8000 /10000 /12000 /16000mm
Maximum Cutting Length :	1850 /2850 /3850 /4850 /5850 /7850 / 9850 /11850 /15850mm
Headstock
Spindle Bore :	Ø 130 mm
Spindle Taper :	Ø 140 mm
Spindle Nose :	A2–15
Spindle Speed :	3.15 — 315 RPM
Tooling Turret
Tool Post Station :	4-Station Electric Turret (6 or 8-station is optional )
Max. Size of Tool Post :	50 X 50 mm
Travel
Max. Travel of X-Axis :	800 mm	850 mm	850 mm	850 mm
Max. Travel of Z-Axis :	2000 /3000 /4000 /5000 /6000 /8000 /10000 /12000 /16000mm
Rapid Speed of X-Axis :	3000 mm /min
Rapid Speed of Z-Axis :	4000 mm /min
Tailstock
Tailstock Taper :	Metric 80
Tailstock Quill Diameter :	Ø 260 mm
Tailstock Quill Stroke :	300 mm
Precision
Positioning Accuracy :	± 0.020 mm
Repeat Positioning Accuracy :	± 0.010 mm
Drive Capacity
Main Motor :	30 KW
Packing Type :	Export Type
Gross Weight :	22180 KGS ( For DLE–CNC 850 X 3000 )
Packing Size :	8650 X 3250 X 2580 mm ( For DLE–CNC 850 X 3000)
Standard Accessory :	CNC Control System, 4-Jaw Lathe Chuck, 4-Position Electrical Turret, Lubrication System, Coolant System, Machine Lamp, Tools and Toolbox
