Horizontal Machining Center
SIEMENS / FANUC / GSK
630 X 630 mm
1000 mm
800 mm
800 mm
1200 KGS
Main Feature
Convincing Arguments: Quality, Efficiency and Price
Rigid Large Working Table 630 X 630 mm
Maximum Load Capacity on Table 1200 KGS
FANUC or SIEMENS CNC Control System for multi-function and user-friendly
Higher Productivity with Single or Double Positions of Work-table is Optional
High Duty Version
Double Positions of Work-table for higher productivity
Precision Linear Guide-ways for enhance Rigidity and Durability
High Precision Germany Original FAG Bearings Ensures Longer Service Life
Integrated Machine Lamp in Work Space
Automatic Chip Conveyor ensures efficient chip discharge
EMC Electromagnetic Compatibility and Safety
Fast rapid motion speed of 36 m / min
Rigid Construction for Efficient and Reliability Machining
Portable Electronic Hand-wheel
Automatic Tool Changer with 40 tools is Optional
FANUC CNC Control System is optional
Certificate of Original (CO, FORM A, FORM E, FORM F)
Technical Data
Product Name : | Heavy Duty CNC Horizontal Machining Center |
Product Item : | MM-HMC 630 |
Control System : | FANUC or SIEMENS CNC Control System |
Work-table Quantity : | 1 Pallet (optional is 2 pallet) |
Machine Data | |
Table Size : | 630 X 630 mm |
Maximum Load On Table : | 1200 KGS |
Table Indexing Angle : | 1° X 360 ° |
Spindle Taper : | BT 50 |
Spindle Speed : | 30 — 3000 RPM |
Spindle Torque : | 660 N.m |
T-slots (number /width /distance) : | 5 piece X 18 mm X 100 mm |
Distance from Spindle Axis to Table Surface : | 100 — 900 mm |
Distance from Spindle Nose to Table Center : | 150 — 950 mm |
Travels | |
Travel X -axis : | 1000 mm |
Travel Y -axis : | 800 mm |
Travel Z-axis : | 800 mm |
Feed | |
Rapid Feed (X / Y / Z-axis) : | 24 / 24 / 24 m /min |
Cutting Feed : | 1 — 10000 mm / min |
Precision | |
Positioning Accuracies : | ± 0.01 mm |
Repeat Positioning Accuracies : | ± 0.005 mm |
Tool Changer | |
Tool Magazine Capacity : | 24 tools |
Tool Magazine Type : | Arm Type |
Max. Tool Weight (per piece) : | 25 KGS |
Max. Tool Dimensions : | Ø 110 X 400 mm / Ø 220 X 400 mm |
Drive Capacity | |
Main Motor : | 15 / 18.5 KW |
Gross Weight : | 13158 KGS |
Packing Size : | 5860 X 3990 X 3180 mm |
Standard Accessory : | FANUC Oi MF CNC Control System, Linear Guide-ways, Tool Magazine, Automatic Chip Conveyor, Working Lamp, Lubrication system, Alarm Light, Tools and Toolbox |
