Heavy Universal Milling Machine
2000 X 500 mm
1400 mm
700 mm
500 mm
7.5 KW
Main Feature
Convincing Arguments : Quality, Efficiency and Price
Table size 2000 X 500 mm, Table load 1800KGS, Spindle taper ISO50, Main Motor 7500W
Preload Ball screws on all Three-axes with ZERO backlash for easy and precise feeds
Dynamic infinitely variable speed and rapid feed driven by powerful, separate Servo Motors on every axes (all X-/Y-/Z-axis)
Large dovetail guiding X-axis, rectangular guiding in Y-axis and Z-axis guarantees stability
Electronic Hand-wheels integrated in swivel-able control panel for easy operation
Stepless feed settings and rapid feed in all axis driven by separate three Servo Motors
Extra large work table and wide travel ranges on all Three-axes
Universal swivel head – cutter can be moved to any spatial angle
Central lubrication for guide-ways comes standard
Double supporting column for big load and high accuracy
Mechanical change speeds in head stock for powerful machining capacity
Large cross table with T-slots treated surface for heavy work-piece load
Machine body in heavy cast iron construction for vibration-free run
Clearly arranged spindle speed control unit on machine arm
Turcite-B coating in X-axis reduces slip-stick effect
Swivel milling head can machine any angle surface through front half-sphere
3-axis Digital Position Indicator is optional special spare parts
Hardened, nitrated and polished gear wheels in oil bath
Rigid torsion-proof construction with additional guide columns for constant precision when machining heavy work-pieces
Universal milling head swivel 360 degree can be set to various angles
Fine-stepped spindle gears for powerful machining
Optimal adjustment spindle speed and feed for economic machining of various materials
Precise dovetail guides on X-axis, wide square guides on Z-axis
Ball screws in all three-axes to guarantee high accuracy
Central lubrication for 3-axis (X/Y/Z-axis) are standard equipment
Certificate of Original (CO, FORM A, FORM E, FORM F)
Technical Data
Product Name : | Universal Milling Machine with Servo Motor and Ball Screws |
Product Item : | MM-UWF15S |
Working Area | |
Table Size : | 2000 X 500 mm |
Max. Load Capacity of Table : | 1800 KGS |
Number of T-slot : | 5 Pieces |
T-slot Width : | 18 mm |
T-slot Spacing : | 80 mm |
Milling Head | |
Spindle Taper : | ISO 50 |
Spindle Speed : | 30-2050 RPM (27 kinds) |
Milling Head Swivel Range : | 360 degree |
Distance from Spindle Nose to Table Surface : | 50-550 mm |
Throat : | 45 -745 mm |
Travels | |
Max. Travel Longitudinal (X) : | 1400 mm |
Max. Travel Cross (Y) : | 700 mm |
Max. Travel Vertical (Z) : | 500 mm |
Feeds | |
Feed Speed Horizontal (X) : | 10—1000 mm/min (variable speed) |
Feed Speed Cross (Y) : | 10—1000 mm/min (variable speed) |
Feed Speed Vertical (Z) : | 5—500 mm/min (variable speed) |
Rapid Feed X-axis : | 2200 mm /min |
Rapid Feed Y-axis : | 2200 mm /min |
Rapid Feed Z-axis : | 1100 mm /min |
Drive Capacity | |
Main Motor : | 7500 W |
Motor Rating X-axis Feed : | 15 Nm (Servo Motor) |
Motor Rating Y-axis Feed : | 15 Nm (Servo Motor) |
Motor Rating Z-axis Feed : | 18 Nm (Servo Motor) |
Gross Weight : | 6000 KGS |
Packing Size : | 2990 X 2260 X 2180 mm |
Standard Accessory : | Servo Motor in all Three-Axis (X/Y/Z-axis), Coolant System, Ball Screws in all Three-Axis (X/Y/Z-axis), Central Lubrication, Universal Swivel Head, Work Lamp, Tools and Toolbox |
